NEW 6ES7288-3AR04-0AA0

The 6ES7288-3AR04-0AA0 is a SIMATIC S7-200 SMART analog input module, specifically the SM AR04 RTD module. It is designed for use with RTD (Resistance Temperature Detector) temperature sensors and features 4 analog inputs.

The module has a product type designation of SM AR04, with an AI RTD 4×16 bit configuration. It operates at a rated DC voltage of 24V, with a tolerance of -15% to +20%. The typical current consumption is 40mA, and it draws a typical current of 80mA from the backplane bus at 5V DC. The power loss is typically 1.5W.

The input range of this module is limited to RTDs and resistors, with no support for voltage, current, or thermocouple inputs. The analog value resolution for each channel is 16 bits.

The module has a compact design, with dimensions of 45mm in width, 100mm in height, and 81mm in depth, and it weighs approximately 150g. It is suitable for control room installation and is a module – type device.
